SmartPlant P&ID Training is designed for professionals who want to learn how to create, edit, manage, and work with Piping and Instrumentation Diagrams (P&IDs) using Hexagon’s SmartPlant P&ID. You will learn to work with process equipment, piping, valves, instruments, symbols, and engineering data while understanding how P&IDs support engineering design workflows. The training is suitable for process engineers, piping engineers, instrumentation engineers, designers, CAD professionals, and other engineering professionals who work with P&ID documentation. By the end of the training, you will have understanding of key SmartPlant P&ID tools and workflows used to develop and manage P&ID drawings and related engineering data.

Enroll Now

Overview

Prerequisites for SPPID Training

Basic knowledge of P&ID concepts and engineering drawings.
Basic understanding of process plants, piping and instrumentation.
Basic computer skills and familiarity with working in a Windows-based environment.

What Will You Learn?

Create and manage intelligent P&ID drawings.
Create and edit equipment, piping components, pipe runs, and instrumentation.
Work with equipment nozzles, process connections, and flow directions.
Manage item properties, tags, labels, and annotations.
Use Catalog Explorer, stockpile items, filters, and display sets.
Identify and resolve design inconsistencies using validation tools.
Create reports and extract P&ID and plant data.
Manage drawing versions, revisions, printing, and publishing.
Publish and retrieve P&ID data through SmartPlant integration.

Key Features

Instructor Led Training : 24Hrs
1 On 1 Training Option Available
Small Batches Upto 10 Participants
24 X 7 Lifetime Support & Access
Experienced & Professional Trainers
100% Job Assistance

Course Curriculum

Lesson 1 - Introduction to SmartPlant P&ID

1. SmartPlant P&ID interface and navigation

2. P&ID drawing environment

3. Plant model and data structure

4. Catalog Explorer and stockpile

Lesson 2 - Creating P&ID Drawings

1. Creating and managing P&ID drawings

2. Placing equipment

3. Placing piping components

4. Placing instrumentation

5. Working with assemblies

Lesson 3 - Piping and Process Connections

1. Creating and editing pipe runs

2. Connecting piping components

3. Working with equipment nozzles

4. Process line connections

5. Flow direction

Lesson 4 - Properties, Tags, and Labels

1. Managing item properties

2. Item tags and tag validation

3. Creating and placing labels

4. Component and break labels

5. Title blocks and flow arrows

6. Item notes and annotations

Lesson 5 - Editing and Managing P&IDs

1. Editing and modifying P&ID components

2. Moving, copying, and deleting items

3. Working with drawing views

4. Display sets and filters

5. Managing drawing information

Lesson 6 - Design Validation and Consistency Checking

1. Identifying design inconsistencies

2. Using inconsistency indicators

3. Reviewing consistency-check results

4. Resolving design inconsistencies

Lesson 7 - Reports and Data Extraction

1. Generating drawing reports

2. Generating plant reports

3. Equipment and pipe run reports

4. Working with report templates

5. Creating customized reports

Lesson 8 - Drawings, Revisions, and Output

1. Drawing versions and revisions

2. Printing P&ID drawings

3. Managing drawing output

4. Publishing P&ID documents

Lesson 9 - SmartPlant Integration

1. SmartPlant integration concepts

2. Publishing P&ID data

3. Retrieving plant information

4. Data exchange with other SmartPlant applications

5. Integration considerations for Smart Instrumentation
